Raymarine Evolution ACU Specifications
| Model | ACU-100 | ACU-200 | ACU-300 | ACU-400 |
| E70098 | E70099 | E70139 | E70100 | |
| Drive Current Output | Maximum continuous
7 A at supply voltage |
Maximum continuous 15 A at supply voltage | Maximum continuous 5 A
at supply voltage |
Maximum continuous
30 A at supply voltage |
| Drive Clutch Output | No clutch connection | Up to 2.0 A continuous, selectable between 12 /24 V | No clutch connection |
|
| Connections |
|
|
|
|
| Nominal supply voltage |
12 V |
12 V or 24 V |
||
| Operating voltage range |
10.8 V to 15.6 V dc |
10.8 V to 31.2 V dc |
||
| Power consumption (standby) – main power supply |
300 mA (12V) |
300 mA (12/24 V) |
||
| Power consumption (standby) – SeaTalkng power supply |
No power supply to SeaTalkng&nbs p; |
20 mA (12V) |
||
| SeaTalkng LEN
(Load Equivalency Number) |
1 |
|||
| SeaTalkng Power out |
No power supply to SeaTalkng |
3 A at 12 V (fuse protected at 3 A) |
||
| Data connections |
SeaTalkng |
|||
| Installation environment |
Operating temperature: -20C to +55C (-4F to +131F) Storage temperature: -30C to +70C (-22F to +158F) Relative humidity: max 93% |
|||
| Waterproof rating |
Connector panel: IPX2 Drive electronics: IPX6 |
Drip resistant |
||
| Dimensions
(W xH x D) |
180 mm x 140 mm x 52 mm (7.1 in x 5.5 in x 2.0 in) |
285 mm x 211.5 mm x 64.5 mm (11.2 in x 8.3 in x 2.5 in) |
||
| Weight |
0.6 kg (1.32 lbs) |
2.2kg (4.84 lbs) |
||
| Conformance |
Europe: 2004/108/EC Australia and New Zealand: C-Tick, Compliance Level 2 |
